Moticam S3

ยี่ห้อ : Motic

The new Motic sCMOS cameras developed by German engineering represent a new impetus to manufacturing quality, technical precision and lightweight design. With a member of this line the door for new application fields opens wide. The accelerated data readout (Rolling Shutter) also enables to work on fast moving phenomena.

The Moticam S3 delivers a mid-size resolution of 3MP, allowing a balance between speed and resolution. For teaching purposes and routine labs, diverse tasks from biology, medicine and industry are covered. The backlight technology of the sCMOS sensor guarantees state of the art imaging for professional image results.

MOTICAM S3 Specification Details

Sensor type	sCMOS
Sensor size	1/2.8"
Image area	6.44mm (Diagonal)
Capture resolution	3MP
Live display mode through USB	2048 x 1536, 1920 x 1080pixels
Pixel size	2.5 x 2.5μm
Scan mode	Progressive
Shutter mode	Rolling Shutter
Data transfer	USB 3.1
Max. frames per second (fps*)	2048 x 1536 @ 60fps 1920 x 1080 @ 60fps
Exposure time	21 μsec to 2 sec
Operating temperature	From -10 to +60 Degrees Celsius non condensing
Sensitivity	600mV(G) @ 1/30 sec
Support device	TWAIN, SDK and DirectShow Driver
Supported OS	Microsoft Windows 7/8/10, MAC OSX10.9, Linux or higher
Minimum computer requirements	2GHz dualcore - RAM memory 2GB - Video memory min. 512 MB
Lens mount	C-Mount
Software	Motic Images Plus 3.0 for Windows, OSX and Linux
Power supply	100-240V (CE)
Functions	Still image and video capture, live and still image measurement, image adjustments, white balance, automatic & manual exposure, individual objective calibration system.
Power supply	5V (from USB Port)
Package includes	CS ring adaptor, USB 3.1 cable, Motic 4-dot calibration slide, Motic Images Plus 3.0 for PC/OSX/Linux
